Antistatic Spunbonded Nonwovens
ANTISTATIC ALUMINUM COATING SERIES
* Explosion-proof Antistatic PET Filter Media: PET-AL/260
* OLEO/HYDROPHOBIC Antistatic Spunbonded Material: PET-ALF2/260
* Hot Melt PTFE Membrane Explosion-proof Media: PET-ALF4/260
* Nano fiber Treatment Spunbonded Polyester: PET-ALN/260
AL-TYPE |
Appearance | Grey, un-corrugated |
|
|
|
|
Use | Foldable filter media |
|
|
|
|
Composition | Spunbonded polyester with Antistatic Treatment |
|
|
|
|
Product Code | PET-AL/260 | PET-ALF2/260 | PET-ALF4/260 | PET-ALN/260 |
|
Weight(g/㎡) | 260 | 260 | 260 | 260 |
|
Thickness (mm) | 0.55 | 0.55 | 0.55 | 0.55 |
|
Air Permeability
(l/㎡.s) a | 150 | 150 | 40-60 | 150 |
|
Filtering Precision b /Efficiency c | 5μm
(≥99.5) | 5μm
(≥99.5) | 0.3μm
(≥99.99) | 1.0μm
(≥99.9) |
|
Temperature (℃) | ≤65 | ≤65 | ≤65 | ≤65 |
|
Strength | Warp (N/5cm) | 380 | 380 | 380 | 380 |
| Weft (N/5cm) | 440 | 440 | 440 | 440 |
MERV d | MERV11/F6 | MERV11/F6 | MERV16/H11 | MERV14/F8 |
|
Remarks |
| Moisture-proof Processing | PTFE Membrane | Nano-fiber Membrane |
|
Application | Coal transportation, Coal collection, Flour, Aluminium powder, Zinc dust…Explosion-proof function |
|
|
|
|
This series is not suitable for high humidity, acid and alkaline environments. |
Aluminum coated media is coated with a layer of conductive aluminum to make it being anti-static and anti-explosion. in addition, we can add oil, water, dirt repellent treatment on the material according to actual situation. This series are not applicable for environments of acid, alkaline, and high humidity.
a. Air Permeability was tested at △P=200Pa.
b. Filtration Precision, this data refers to the minimum grade of particle size that can be effectively blocked before the initial "dustcake" is established. In the practical using processes, we can improve the filtration precision by using correct filtration velocity, and establishing stable initial "dustcake", etc.
c. Filtration Efficiency was tested by using 8-12 micron 325 mesh talcum powder as test dust with the filtration speed ≤ 1.2m/ min and the concentration of dust (4±0.5) g/m3, after more than 5 times cleaning process, filter media makes a good effect on the ratio of filter effectively blocking dust and the total quantity of dust. (JB/T 10341-2014)
d. Filtration Precision Level is tested at the beginning of using, by ASHARE52.2 in USA or EN779 in Europe.
★The various functions of the filter media can be combined with each other, please contact us with your special needs.
★All technical parameters are for reference only (test data may deviate due to test different conditions and equipment), we reserve the right of making changes without prior notice.
