Rectangular Top Flange Filter Cartridge

Quantity:

Rectangular Top Flange Filter Cartridge

Square Flange Filter Cartridge - E TYPE

Model

E-PET-406*360-3266F1

E-CE-406*360-3266N

Size

Φ406*Φ360-Φ325*Φ215*660MM


Media Type

PET-F1/260

CE-N/120

Filter Media

100% Spun bonded Polyester

80/20
Blend Cellulose with NANO Fiber Membrane

Filtration Area

9.4m2

21m2

Filtration Precision

5μm

1μm

Precision Grade

MERV11/F6

MERV14/F8

Filtration Efficiency

≥99.5%

≥99.9%

Rated Flow

≤680m3/h

≤1250m3/h

Recommended Air Flow

≤450m3/h

≤600m3/h

Working Temperature

≤80℃


Initial Resistance

≤70Pa

≤120Pa

Metal treatment

Powder spray coating metal/stainless steel mesh


★Other changes will be depended on the demand of client.


Polyester nonwoven fabric or wood pulp fiber filter paper can be used.
Independently research and develop filtration materials to solve filtration problems.
